SXT Series
Engineered for demanding marine applications, the SXT Series Rugged Sunlight-Readable Touch Monitors deliver outstanding visibility, durability, and touch performance in harsh environments. Featuring a high‑brightness optically bonded display, full IP66/67 waterproof sealing, and a robust die‑cast aluminum enclosure, these monitors ensure reliable operation in any weather or lighting condition. The advanced PCAP touchscreen remains fully readable even with polarized sunglasses.
Features
- Display Type: Sunlight Readable / Night Dimmable LED LCD
- Technology: Optically Bonded Active Matrix
- Touchscreen: Projected Capacitive (PCAP) Multi-Touch
- Brightness: 1,000 to 1,500 nits (model dependent)
- Contrast Ratio: 1000:1 (typical)
- Viewing Angles: 85°/85°/85°/85° (Left/Right/Up/Down)
- Waterproof Rating: Full IP67 Sealed Front Face (IP66 Enclosure)
- Housing Material: Marine-Grade Die-Cast Aluminum
- Video Inputs: DVI, HDMI, VGA, and Composite (BNC)
- Control Ports: USB (for touch control) and RS232
- Power Input: 9–36V DC Wide Range (Optional AC power supply)
- Operating Temperature: -10°C to 55°C
- Storage Temperature: -20°C to 60°C
- Dimming Capabilities: 0–100% Manual Potentiometer or Front Panel Keys
- Mounting Options: VESA Mount (75mm/100mm) or Console Panel Mount
Manual
Data Sheet
