R9000E-AI Industrial Computer
Rugged Computer w/ LGA 1200 for Intel 10th Gen CPU & W480E PCH, 2x PCIe/PCI Expansion
Features
- Intel® Core™ i7-10700TE, 8 Cores, 16MB cache, up to 4.4 GHz
- Intel® W480E chipset
- 32GB DDR4 Memory
- 1TB 2.5″ SATA SSD
- NVIDIA ATX A2000 12GB
- 4x mDP, 2x DisplayPort, 1x DVI-I
- 2x Intel® GbE supporting Wake-on-LAN and PXE
- 2x Full-size Mini PCIe for communication or expansion modules, 2x SIM socket
- 1x M.2 (E Key, PCIe x1, USB 2.0, 2230)
- 8x RS-232/422/485 (6x internal), 6x USB 3.2 Gen 2, 3x USB 3.2 Gen 1 (1x internal)
- 8x DI + 8x DO with isolation
- 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
- Wide Operating Temperature -25°C to 70°C (35W CPU)
- TPM 2.0 Supported
- Wifi / Bluetooth Optional
- Windows 10 IoT Enterprise
- UL Listed
Data Sheet
