FENR-5000 Series Marine CCTV

Superior Fanless Embedded NVR System w/ LGA 1151 for Intel 8th/9th Gen CPU & Q370, PCH, 1x PCIe x16, 1x PCI Expansion

Features

LGA 1151 socket for 8th/9th Gen. Intel® CFL-R S Processor (65W/35W TDP)
Intel® Q370 chipset
2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB
Triple Independent Display by 1x DVI-I and 2x DisplayPort
2x Intel® GbE supporting Wake-on-LAN and PXE
2x Full-size mini PCIe for communication or expansion modules, 2x SIM socket
4x 2.5” SATA HDD Bay and 1x mSATA with RAID 0, 1, 5, 10 support
1x M.2 (M Key, NVMe PCIe x4, 2280); 1x M.2 (E Key, PCIe x2, USB 2.0, 2230)
6x RS-232/422/485 (w/ 2x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1
8x DI + 8x DO with isolation
9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
Wide Operating Temperature -25°C to 70°C (35W CPU); -25°C to 60°C (65W CPU)
1x PCIe x16, and 1x PCI Expansion
TPM 2.0 Supported

Data Sheet

FENR-5000-DS
