RMD-32-P

The RMD-32-P Series is designed from the ground up to meet rigorous environmental requirements. It can be configured with an IP67-rated front face and an IP53-rated back for general rugged applications, or as a fully IP67-rated unit with MIL-SPEC circular connectors for sealed environments. The series comes standard with an EMI ITO lens and offers optional features such as optical bonding, a high-bright backlit LCD monitor, a heated lens, and an NVIS backlighting system.

Built to meet numerous MIL-SPEC standards off the shelf, the RMD-32-P can also be customized to meet specific requirements. It is constructed from 5052-H32 and 6061-T6 aluminum, which are laser-cut and milled to precise standards. For additional protection, the internal components can be conformally coated, and all connections are safeguarded with dielectric grease to prevent corrosion. Internal cabling uses low-smoke, zero-halogen Teflon for enhanced safety and reliability.

Specifically designed for panel mount applications, the RMD-32-P features a milled aluminum front face that rises only 1/2 inch above the mounting surface, combining durability with a sleek, low-profile design.
